ENGINE INFO
engine/Drive Chain
Engine: 229cc，4-Stroke
Cooling System: Air Cooled
Max Power (hp): 14.08/7000rpm
Max Torque: 16.5N.M/5500r/min
Bore * Stroke: 2.64 x 2.56"
Compression Ratio: 9.0:1
Transmission: 5-speed Manual
Start System: Electric/Kick
Ignition: CDI
Final Drive: Chain Drive
Battery: 12V/9Ah

Frame /Body/ Suspension / Brakes
Front Suspension: Double Shocks
Rear Suspension: Central Unit Shock
Front Brake: Hydraulic Disc
Rear Brake: Hydraulic Disc
Front Tire: 80/100-21
Rear Tire: 110/100-18

Capacities / Dimensions
Weight Capacity (lbs): 331
Gross Weight (lbs): 310
Net Weight (lbs) : 265
Overall Length: 82.3"
Overall Width: 36.2"
Overall Hight: 55.1"
Carton: L*W*H: 69x18x34" Seat Height: 35.4"
Wheelbase: 53.9"
Ground Clearance: 8.3"
Gas Tank Capacity(gal): 3.7

Safety / Control
Headlight: Yes
Tail Light: Yes
Turn signal lights: Yes
High beam indicator lights: Yes
Engine Kill Switch: Yes
Horn: Yes
Reflectors: Yes
Foot Brake: Yes

Others
Tool Kit: Yes
EPA Approved Yes

Brand New 70% assembled inside a metal crate. Certified Technician required for Assembly,
Warranty covers 30 days for replacement parts only.
Lift gate included. Residential included. Shipping insurance include. delivery opponents included
